Crane Scales

MSI-3460 Challenger 3

The MSI-3460 with ScaleCore measurement module provides industry leading weighing features of previous Challenger designs plus much more. Long range viewing is enhanced with a larger 1.5 inch (38 millimeter) ultra-bright LED digital display and resolution settings of up to 10,000 divisions for precise 0.1 percent loading accuracy. Product operating time is extended to over 80 plus hours with a single six-volt rechargeable battery. The original signature Challenger packaging has been upgraded to NEMA Type 4/IP65 levels. Manufactured in the USA in strict compliance with the highest safety standards, Challenger continues to sustain minimum 200 percent safe and 500 percent ultimate load ratings.

  • Crane unit with five-digit, 1.5 in (38 cm) LED display • Top lifting eye and bottom swivel hook
  • Lb/kg switch selectable
  • Six volt rechargeable battery and universal 115/230 VAC, 50/60 Hz battery charger (NA plug standard)
  • Meets or exceeds OSHA, ANSI, ASME and other safety design standards (5:1 Ultimate Safety Factor)

Options:

  • Audible alarm
  • Universal direct power supply, 85-265VAC, 47-440Hz / 130-300VDC RF remote controller
  • RF remote display, handheld or desk mountable
Request A Quote

MSI-4260 Port-A-Weigh

After three decades of production, added advancements, and thousands of worldwide installations, the next generation Port-A-Weigh embedded with ScaleCore technology continues to reign as the industry standard. Along with Port-A-Weigh, the MSI product offering features the most comprehensive line of industrial crane scales and specialized overhead weighing solutions. For medium- to heavy-capacity and duty-cycle needs, the MSI-4260 meets or exceeds all industrial safety requirements, including OSHA, ANSI and ASME and is an economical choice for many bridge crane, foundry, and in-process material handling needs.

  • Crane unit with 5-digit, 1.2 in (30 mm) LED display
  • Top lifting eye or shackle, bottom thrust bearing swivel hook
  • 12 volt rechargeable battery and universal 115/230 VAC, 50/60 Hz battery charger (NA plug standard)
  • NEMA 4 IP66 rated, not safe for emersion but able to be used outdoors
  • Intrinsically Safe configurations available
  • Optional approvals: FM cFM and ATEX
Request A Quote

Intercomp CS1500

With large, easy-to-read LCD or LED displays, CS1500™ high performance crane scales are available in a range from 500lb (250kg) to 20,000lb (10,000kg), are NTEP certified, and boast best-in-class battery life. Both models come standard with RFX™ Wireless Weighing Technology enabling cable-free control and monitoring of scales. They also feature USB/RS232 output, multi-scale communication, and a multitude of remote display options.

  • 500 lb (250 kg) to 20,000 lb (10,000 kg) Capacities
  • Accuracy of ±0.1% of Reading
  • Large, Easy-to-Read, LED or LCD Display
  • NTEP Certified Models Available
  • Commercially Available D-Cell Batteries Last up to 3,000 Hours in Scale
Request A Quote

Intercomp CS3000

Available in capacities ranging from 2,000lb (1,000kg) to 100,000lb (50,000kg), the CS3000™ crane scale features fully integrated RFX™ Wireless Weighing Technology and is built to thrive in harsh environments. All crane unit electronics are shock-mounted in a weatherproof case and provide maximum protection against moisture, dust and rough usage. Commercially available batteries offer industry leading battery life, minimizing down time due to battery charging or replacement.

  • 2,000 lb (1,000 kg) to 100,000 lb (50,000 kg) Capacities
  • Accuracy of ± 0.1% of Reading
  • NTEP Certified Models Available
  • Large, Easy-to-Read, LED or LCD Display
  • Wireless Signal up to 300’ (90m) Line of Sight
  • Commercially Available D-Cell Batteries Last up to 3,000 Hours in Scale
Request A Quote

Champion Scale offers a wide variety of additional products to meet your weighing needs.
Please feel free to contact us to discuss other weighing solutions.
